GHS 175 x 5 x 8130 FC
1 / 5
Front-End Cylinders FC Cylinders

GHS 175 x 5 x 8130 FC

Product Code: 4317558130649

Hidromas telescopic front-end cylinders are engineered specifically for straight headboard types, capable of handling tipping weights up to 100 tons. Our trunnion-type FC cylinder is lightweight, robu...

Product Description

Hidromas telescopic front-end cylinders are engineered specifically for straight headboard types, capable of handling tipping weights up to 100 tons. Our trunnion-type FC cylinder is lightweight, robust, maintenance-free, and provides superior stability to the tipper. Hidromas FC tipping cylinders have established a strong reputation for their reliability and cost-effectiveness over many years.

Product Specifications

Effective Diameter (mm)175
Stroke (mm)8130
Working Pressure (bar)250
Max Working Pressure (bar)-
Stages5
Duty SegmentStandard

Download Documents

4317558130649 GHS 175-5-8130 H K486.pdf
GHS 175 x 5 x 8130 FC.pdf
